Ranger Nano 2.4GHZ ELRS Module

Ranger Nano 2.4GHZ ELRS Module

by Radiomaster

$39.99 - $39.99

$39.99

$39.99 - $39.99

$39.99

Features

High-efficiency cooling system
Wifi and Bluetooth support
Packet rates up to F-1000Hz
T-antenna included
With the Nano connector, support Zorro radio

Specification

Item: Ranger Nano Module
Regulatory Domain: ISM2400
MCU: ESP32(main), ESP8285(aux,as ESP backpack)
RF chip: SX1281IMLTRT
Frequency Range: 2400 MHz - 2480 MHz
Maximum packet rate: 500Hz/F-1000Hz (F-1000Hz mode requires EgdeTX 2.7.1 or later)
Minimum receiver refresh rate: 25Hz
RF Output Power: Default 100mW
Wifi Support: Yes
Bluetooth support: Yes
XT30 Power supply voltage: DC 6V - 16.8V
Weight: 48g (with antenna) / 39g (without antenna)
Dimension: 136*42*26mm (with T antenna) / 74*42*26mm (without antenna)
